    DBT280 240KVAPLC Inverter Spot Welder PLC For Auto Parts Industry

    Ask Lasest Price
    Brand Name : PDKJ
    Model Number : DBT280
    Certification : ISO CE SGS
    Price : USD 45000-65000 per unit
    Payment Terms : L/C, T/T
    Supply Ability : 100 set per month
    Delivery Time : 7-25 days
    • Product Details
    • Company Profile

    DBT280 240KVAPLC Inverter Spot Welder PLC For Auto Parts Industry

    80-450KVA Pneumatic Spot Welding Machine and Projection Welding Machine In Auto Parts Industry

    High power medium frequency inverter DC spot (Projection)welding machine


    Product highlights: balanced three-phase power input, small impact of DC output on user power grid, energy saving, stable current, high welding quality.

    MF DC Inverter Spot Welder is a set of advanced welding equipment. The welding transformer is in small size but the outout energy is large. Three-phase AC will be converted into DC after being rectified. Then the DC will be converted into medium frequency 1000HZ square wave to be connected to primary welding transformer through the inverter circuit which is composed of IGBT. The MF square wave will become small pulse DC to the electrode for welding work piece through the depressurization and recitifying process in the welding transformer. The Inverter will adjust the duty ratio of IGBT through the feedback of secondary current so as to achieve constant current of the welding process.


    Product parameters


    ParameterDTB-240DTB-280DTB-340DTB-450
    Rated capacity240KVA240KVA340KVA450KVA
    Power Supply3φ380V3φ380V3φ380V3φ380V

    Max.short-circuit current

    50KA65KA80KA100KA

    Duty Cycle rate

    20%20%20%20%
    Control modeInitial gradation constant current

    Inverter frequency

    1000HZ1000HZ1000HZ1000HZ
    Arm extension size500×350mm500×350mm500×350mm500×350mm

    Max. Work pressure

    12000N12000N12000N12000N

    Electrode stroke

    100mm100mm100mm100mm

    Cooling water flow

    14L/min14L/min16L/min20L/min

    Weld ability / aluminum plate

    3.0+3.0mm3.5+3.5mm4.0+4.0mm5.0+5.0mm

    Weld ability / carbon steel

    4.0+4.0mm4.5+4.5mm5.0+5.0mm6.0+6.0mm

    Electrode arm size

    φ74x195mmφ74x195mmφ74x195mmφ74x195mm

    Electrode holder size

    φ31.6×250mmφ31.6×250mmφ31.6×250mmφ31.6×250mm

    Electrode head size

    φ20x60mmφ20x60mmφ20x60mmφ20x60mm
    Weight750kg820kg900kg980kg
    Dimensions1205*870*2140mm1205*870*2140mm1205*870*2140mm1205*870*2140mm

    Product Characteristics


    ■ High-quality and high-efficiency welding capacity High-quality and high-efficiency welding capacity, power factor up to 98%, three phase input load balance.The impact on the consumer grid is greatly reduced.
    ■ The output current is DC, the current is smooth, and the inductive reactance is zero, the working frequency is 1000hz, the time control precision is 1ms.
    ■ The fuselage adopts the mechanical structure design of high quality steel plate, the overall beauty, good rigidity, which ensures the realization of the stable welding quality.
    ■ Integrated electrode and voltage mechanism, short air circuit, compact structure, quick response, convenient installation and maintenance
    ■ The secondary circuit adopts high quality conductive material,which greatly reduces the circuit impedance.
    ■ The reversing valve of the cylinder adopts the famous brand imported from abroad, which has the advantages of quick response,large flow,long life and high speed dotting.
    ■ The standard components adopts international famous brand, so that the overall quality of the welder can reach the first-class level.

    APPLICATION


    Widely applied to welding battery ,lighting electric resource automobile.medical apparatus and instruments,photoelectric communication, micro motor as well as requested chip inductor with high temperature enamed round wire/extra fine wire minimum size can be 0.02mm), wire rope,metal wire,nickle cup, can cutting wire and welding ,CCFL filed ,fuse,lamp filament.



    COMPETITIVE ADVANTAGE


    1. PDKJ is the leading brand in resistance welding industry in China for 15 years; Factory direct sale,high quality and competitive price.

    2. Customized Service: We can help to design and develop the welding machine according to your requirement.

    3. Genuine Product with Excellent Quality: 12 months warranty. Our machines are strictly complied with ISO9001:2000 and China Compulsory Certification. Most of our machines enjoy more than 8-10 years service life. 100% guarantee test before delivery.

    4. After Sales Service and Technical Assistance: 24 hours technical support by email. Our professional team is always willing to be your technical consultant.
