    25KVA DBT 80 Table Stainless Steel Spot Welder Traceless Medical Devices

    Ask Lasest Price
    Brand Name : PDKJ
    Model Number : DBT80
    Certification : ISO CE SGS
    Price : USD 4500-5500
    Payment Terms : L/C, T/T
    Supply Ability : 200 set per month
    Delivery Time : 7-25 days
    • Product Details
    • Company Profile

    25KVA DBT 80 Table Stainless Steel Spot Welder Traceless Medical Devices

    Desktop Seamless Medium Frequency Inverter Welding Machine Stainless Steel Spot Welder

    Desk AC precision spot welding machine


    Product highlights: desktop structure design, space saving, small current, more precise control, economical


    Specifications


    ParameterDN-25T
    Rated capacity25KVA
    Power Supply2φ380V
    Rated frequency50/60HZ
    Max. short-circuit current15000A
    Load duration rate20%
    Arm extension size120 mm x115mm
    Max pressure750N
    Electrode stroke50mm
    Cooling water flow4L/min
    Weight130kg
    Dimensions800*500*765mm

    Product Characteristics:


    Direct-type Pressure Mechanism:

    The guide part adopts new structure with good mobility


    High Strength Body Structure

    Good rigidity, prevent electrode head from sliding under pressure


    Table Design Structure, Good Looking:

    Especially suitable for high-precision work pieces and assembly line production


    Safe and High-performance Pneumatic System

    Pressure speed can be adjusted.


    Water-saving& Water-circulating Cooling System:

    Equipped with quick water-cooled connector,convenient to replace water-cooled electrode or fixture.


    Equipped with a New Generation of Microcomputer Controller:

    Accurate and stable current, excellent performance


    Application

    Desktop AC precision spot welding machine is suitable for welding electrical switches, wire terminals, hardware, bimetallic pieces and precision workpieces. It is widely used in the welding of precision components such as electronics, electrical appliances, medical devices and instruments.




    FAQ

    1. When can you arrange shippment?
    We usually arrange shippment within 15 days after getting deopsit,but customized machines may be more than 25 days.


    2.Do you inspect the finished products?

    Yes, Each step of production products will be came out inspection by QC department before shipping.

    3.Are you factory?
    Yes, We are factory, all machine is made by ourself and we can provide customize service according to your requirement.

    4.How will you deliver my goods to me?
    We always ship by air and sea in the mean time.

    5.How about your transport packing? Is it possible to damage the machine during the transportation?
    We have rich experience on international transportation. All the packing are extra thickness carton filling with protective PE foam and waterproof membrane. No damage happened during transportation until now.

    6.Can you put my brand name (logo) on this Spot Welder?
    Yes,we can . In order to explore the market better and provide more convenient services to global customers.

    7.What kind of payment do you accept?
    T/T, Western Union, PayPal, .L/C, D/A, etc.
